| Display |
: |
3½ Digit, 12.5mm Red LED display. |
| Range |
: |
20 MΩ TO 20 GΩ |
| Test Voltage |
: |
50V, 100V, 250V, 500V, 1000V DC |
| Resolution |
: |
0.01 MΩ |
| Accuracy |
: |
1.5% + 0.1 MΩ for 20 MΩ range ; + 2% for all other ranges |
| Input Supply |
: |
230V.AC ± 20%, 50Hz. |
| Over Range Indication |
: |
Blanking of all Digits except MSD. |
| Under Range Indication |
: |
LED. |
| Guard |
: |
Avoids spurious leakage current flowing in measurement set up. |
|
